4-20mA Differential Pressure Transmitters Gas Air Wind Pressure Sensor Transmitter

Ask Lasest Price
Brand Name :	Sier
Model Number :	SPT91L
Certification :	CE,RoHS
Price :	USD60~100/Piece
Payment Terms :	T/T, Western Union
Supply Ability :	5000 pieces each month
Delivery Time :	7

Add to Cart

Product Details
Company Profile

4-20mA Differential Pressure Transmitters Gas Air Wind Pressure Sensor Transmitter

Features

1. This differential air pressure transmitter, adopts imported high-precision, high stability micro-pressure chip.

2. The shell is aluminum alloy structure. 2 pressure interfaces are M10 screw thread and cock structure. It can be directly installed on the measuring pipe or connected by the pressure pipe, easy to install and use.
3. The transmitter is widely used in petroleum, chemical industry, metallurgy, electric power and other fields. It effectively controls in power and coal industries, such as boiler ventilation and underground ventilation.

4. Solid shell

Specification

Medium	Gas (weak corrosive and dry)
Range(Pa)	100,200,500,1K,2K3K,5K,10K,20KPa;-100,-200,-500,-1K,-2K,-3K,-5K,-10K,-20K
Range(Pa)	±100,±200,±300,±500,±1K,±2K,±3K,±5K,±10K,±20K
Output	4-20ma (Two-wire system), 0-5vdc, 0-10vdc, 0.5-4.5 VDC (three-wire system)
Accuracy	±0.1%FS,±0.25%FS,±0.5%FS,±1%FS
Power supply	12VDC(9~24VDC),24VDC(15~36VDC)
Overload capacity	150%FS
Insulation resistance	1000 M or more Ω / 100 VDC
Current output type	Biggest 800 Ω
Voltage output type	More than 50 k Ω
Medium temperature	-20~85 ℃
Ambient temperature	-20~85 ℃
Storage temperature	-40~90 ℃
Relative humidity	0~95% RH
Seal grade	Ip65
Response time(10%~90%)	≤10ms
Stability	≤0.15%FS/year
Vibration effect	Less than or equal to + / - 0.15%FS/ year (mechanical vibration
Electrical connection	Frequency: 20Hz ~ 1000Hz
Standard wiring	Direct lead output
Pressure connection	M10
Enclosure material	Aluminum alloy

Outline Construction

(Unit: mm)
