Feathers
1. Stainless steel: Anti-violent vibbration, strong impact,
corrosion-resistant all stainless steel structure, long life
material, resistant to harsh enviroments
2. Laser label: Laser marking, can be customized
3. Installation: Chuck seal or specified, the aspect ratio of the
weld is unmatched by other welding processes
4. Structure: The thick and shallow structure of the inner bore is
effecive o prevent blockage of the slurry and facilitate mainteance
Applicaion
* Oil and gas drilling
* Drilling reinforcement
* Cement grouting
* Hydraulic fracturing
* Cementing and fracturing
* Domestic fracturing truck
Specification
Media to be measured | wet soil, crude oil, corrosive liquids and gases |
| Pressure type | absolute pressure, sealed reference pressure, vent pressure |
| Range | 0～35MPa, 70MPa, 105MPa, 140MPa, 210MPa, 315MPa |
| Power supply | 9-30VDC |
| Output signal | 4-20mA, 0-5VDC, 1-5VDC, 0-10VDC, 3mV/V |
| Nonlinear | 0.04% FS |
| Repeatability | 0.04% FS |
| Accuracy | 0.1% FS, 0.2% FS, 0.5% FS |
| Long-term stability | 0.1% FS / year (typical) |
| Working temperature | -43～85°C/125°C |
| Compensation temperature | -25 ~ 70 ° C / 100 ° C |
| Response time | ≤ 1 millisecond (typical) |
| Insulation resistance | ≥500MΩ/100V |
| Overload pressure | 200% FS (2 times full scale, special: 5 times full scale) |
| Destruction pressure | 500% FS (5 times full scale, special 10 times full scale) |
| Vibration resistance | about 10g/0~2000HZ |
| Vibration resistance | about 10g/0~2000HZ |
| Impact resistance | about 50g/1ms |
| Connection method | Chuck seal or specifified |
| Wetted material | 17-4PH stainless steel |
| Relative humidity | 0～100%RH |
| Protection rating | IP67 |
| Electrical output lead | aerospace connector, Amphenol |
Electrical connection
